Zenerbarrier, D5014D, 2 kanaals, 4-20mA
Power: 24Vdc
SIL 3 / SC 3
Input from Zone 0/Div. 1
Installation in Zone 2/Div. 2
2 fully independent channels
4-20 mA Active-Passive Input, Source-Sink Output
Output current duplication available
HART® compatible
Input and Output short circuit proof
In-field programmability by DIP Switch
High Accuracy
Three port isolation, Input/Output/Supply
High Density, two channels per unit
ATEX
